• With electrical cord, 1.8 m heavy duty cord with tripolar connector
• Connections
• Inlet: 1/2 (F) NPT
• Outlet I.D (Hose barb): 12 mm
Capacity:
• Compressor, Aftercooler: 320 SCFM
• Refrigeration, Air Dryer: 639 SCFM
• Filter, Water Seperator: 3195 SCFM
• Maximum Supply Pressure: 230 PSI
• Working Temperature: 1 to 60 °C
• Voltage: 115 VAC / 1ph / 50-60 Hz
• Ball Valve Strainer included
• Dimensions: (H) 140 mm x (W) 69 mm x (D) 163 mm
Material(s):
• Body: Polyamide
• Chamber: Aluminum
• Valve Internal Parts: Stainless steel
• Diaphragm: Fluoroelastomer
• UL, CE
• No wastage of compressed air
• Electronic condensate drains with digital level control
• Intelligent logic based on an 8-bit microprocessor recording events on an integral flash memory
• "Easy-lock revolving" connection
• Adjustable for vertical and/or horizontal connections
• Integrated filter to collect contaminated condensate
• Easy to clean and maintain
• Remote alarm connection
• Receiver with treatment resistent to most aggressive condensates, like those of oil-free compressors
• Fast easy-lock connection
• Connection: for drainage tube
• Built-in dirt screen easy to clean prevents the solenoid from clogging
• Dry alarm contact - The drain is equiped with a special alarm cycle that starts working in case of trouble
• Revolving top condensate inlet offering an additional balance line connection
• Have been designed to solve the problem of condensation water drainage from production plants and compressed air distribution systems
• Controlled drainage of condensation water without any compressed air leaks
• All versions are suitable for working with any type of condensation water even the most aggressive one or water containing a high percentage of oil
• A built-in receiver of filter, that is easy to clean, prevents the solenoid valve from clogging
